Portrait Matting

Portrait matting produces a soft alpha matte separating the foreground (person) from the background — no trimap needed.

Portrait Matting
MODNet: Input → Matte → Green Screen

Available Models

Model Variant Size Use Case
MODNet Photographic PHOTOGRAPHIC 25 MB High-quality portrait photos
MODNet Webcam WEBCAM 25 MB Real-time webcam feeds

Basic Usage

import cv2
from uniface.matting import MODNet

matting = MODNet()

image = cv2.imread("photo.jpg")
matte = matting.predict(image)

print(f"Matte shape: {matte.shape}")   # (H, W)
print(f"Matte dtype: {matte.dtype}")   # float32
print(f"Matte range: [{matte.min():.2f}, {matte.max():.2f}]")  # [0, 1]

Model Variants

from uniface.matting import MODNet
from uniface.constants import MODNetWeights

# Photographic (default) — best for photos
matting = MODNet()

# Webcam — optimized for real-time
matting = MODNet(model_name=MODNetWeights.WEBCAM)

# Custom input size
matting = MODNet(input_size=256)
Parameter Default Description
model_name PHOTOGRAPHIC Model variant to load
input_size 512 Target shorter-side size for preprocessing
providers None ONNX Runtime execution providers

Applications

Transparent Background (RGBA)

import cv2
import numpy as np

matting = MODNet()
image = cv2.imread("photo.jpg")
matte = matting.predict(image)

rgba = cv2.cvtColor(image, cv2.COLOR_BGR2BGRA)
rgba[:, :, 3] = (matte * 255).astype(np.uint8)
cv2.imwrite("transparent.png", rgba)

Green Screen

import numpy as np

matte_3ch = matte[:, :, np.newaxis]
bg = np.full_like(image, (0, 177, 64), dtype=np.uint8)
green = (image * matte_3ch + bg * (1 - matte_3ch)).astype(np.uint8)
cv2.imwrite("green_screen.jpg", green)

Custom Background

import cv2
import numpy as np

background = cv2.imread("beach.jpg")
background = cv2.resize(background, (image.shape[1], image.shape[0]))

matte_3ch = matte[:, :, np.newaxis]
result = (image * matte_3ch + background * (1 - matte_3ch)).astype(np.uint8)
cv2.imwrite("custom_bg.jpg", result)

Webcam Matting

import cv2
import numpy as np
from uniface.matting import MODNet

matting = MODNet(model_name="modnet_webcam")
cap = cv2.VideoCapture(0)

while True:
    ret, frame = cap.read()
    if not ret:
        break

    matte = matting.predict(frame)
    matte_3ch = matte[:, :, np.newaxis]
    bg = np.full_like(frame, (0, 177, 64), dtype=np.uint8)
    result = (frame * matte_3ch + bg * (1 - matte_3ch)).astype(np.uint8)

    cv2.imshow("Matting", np.hstack([frame, result]))
    if cv2.waitKey(1) & 0xFF == ord("q"):
        break

cap.release()
cv2.destroyAllWindows()

Factory Function

from uniface.matting import create_matting_model
from uniface.constants import MODNetWeights

# Default (Photographic)
matting = create_matting_model()

# With enum
matting = create_matting_model(MODNetWeights.WEBCAM)

# With string
matting = create_matting_model("modnet_webcam")
